Reverse Osmosis (RO) Plants
High-purity water for demanding industrial applications — engineered by Thermax, commissioned by Hydrocare.
Producing High-Quality, Salt-Free Water
Reverse Osmosis (RO) is the most widely used membrane technology for producing high-purity, dissolved-salt-free water. It is capable of treating feed water sources ranging from municipal supply to highly mineralized bore well water.
As a trusted Thermax Channel Associate, Hydrocare Engineers designs, supplies, erects, and commissions robust Thermax RO systems across South Gujarat. Our solutions are backed by genuine Thermax spares, membrane supply, and expert after-sales support to keep your operations running continuously.
How It Works
Understanding the technology behind high-purity water production.
Pressurization
Pre-treated feed water enters the system and is pressurized by high-pressure pumps.
Membrane Entry
The pressurized water is forced into the spiral-wound semi-permeable membrane modules.
Salt Rejection
Membrane barriers block 95-99% of dissolved solids, organic compounds, and microorganisms.
Permeate Outlet
Pure water (permeate) flows through the core tube to storage tanks for process or utility use.
Concentrate Discharge
The rejected concentrated brine stream is discharged or sent to wastewater recovery units.
System Configuration & Treatment Stages
Multi-stage Treatment| Stage | Treatment Stage | Technical Purpose |
|---|---|---|
| Stage 1 | Pre-filtration (PSF / ACF) | Removes suspended solids, sediment, turbidity, and free chlorine to protect RO membranes from physical fouling and chemical degradation. |
| Stage 2 | Antiscalant Dosing | Injects specialized scale inhibitors to prevent hardness scale (calcium, magnesium) from precipitation and scaling on the membrane surfaces. |
| Stage 3 | High Pressure Pump | Elevates the pressure of the pre-treated water to overcome naturally occurring osmotic pressure, driving water molecules through the membrane. |
| Stage 4 | RO Membrane Array | The core of the system. Accomplishes 95–99% total dissolved solids (TDS) reduction, removing heavy metals, bacteria, and complex molecules. |
| Stage 5 | Post-treatment (Optional) | Custom pH correction, UV sterilization, de-mineralization, or carbon polishing to meet exact client requirements and process water standards. |
Key Features
Thermax RO Systems are built with premium materials and intelligent controls for reliable performance.
Automatic Controls
Microprocessor-based control panels automate the startup, production, flushing, and safety shutdown cycles, requiring minimal manual oversight.
Clean-In-Place (CIP)
An integrated Clean-In-Place (CIP) provision allows operators to perform routine membrane chemical cleanings easily, restoring flux and extending lifetime.
High Recovery Design
Advanced engineering and membrane configuration enable optimal water recovery rates of up to 75%, significantly minimizing raw water intake and waste.
FRP or SS Vessels
Equipped with premium quality Fiber-Reinforced Plastic (FRP) or rugged Stainless Steel (SS) pressure vessels designed to withstand high working pressures.
Automatic Flushing
The system automatically flushes the membrane surfaces with clean permeate water during shutdown, clearing high-concentration brine and scale deposits.
Optional Remote Monitoring
Integrates with SCADA and smart IoT dashboards for remote monitoring of flow rates, pressure readings, water conductivity, and alarm indicators.
Industrial Applications
Delivering high-purity water to critical manufacturing and utility operations.
Pharmaceuticals
Provides critical pre-treatment for Water For Injection (WFI) systems, active ingredient manufacturing, formulation water, and pure steam generators.
Chemicals
Supplies pure boiler feed water to prevent tube scaling, process reaction water, dilution water, and cooling system makeup water.
Textiles & Dyeing
Provides pure process water for textile softeners, dyeing baths, and print washing, preventing mineral deposits from affecting fabric color consistency.
Food & Beverages
Delivers pure ingredient water for beverage reconstitution, clean-in-place (CIP) sanitize water, food formulation, and boiler feed water.
Hospitals
Supplies high-purity water for sensitive hemodialysis units, medical instrument sterilization autoclaves, and diagnostic laboratories.
General Industry
Provides commercial drinking water, central utility water, plant cleaning, and reliable boiler/cooling tower water across diverse industrial parks.
Our Services
Complete lifecycle engineering support from design concept to continuous operations.
System Supply
Custom design and supply of state-of-the-art Thermax RO plants tailored precisely to your raw feed water analysis parameters.
Erection & Commissioning
On-site plant erection, piping, electrical integration, and system start-up by certified Hydrocare commissioning engineers.
Annual Maintenance Contracts (AMC)
Preventive maintenance programs, regular instrument calibration, and site visits to ensure optimal plant efficiency and longevity.
Membrane Replacement
Fast supply and replacement of genuine Thermax RO membrane elements to restore rejection rate and flow capacity.
Spares Supply
Ready local stock of genuine high-pressure pumps, pressure gauges, flow meters, dosing systems, and filtration media.
Retrofit & Upgradation
Modifying and expanding existing RO skids to boost capacity, automate controls, or improve water recovery percentages.
Need a Reliable RO Solution?
Partner with Thermax and Hydrocare to design and install an energy-efficient RO system optimized for your factory's specific water source.
